My 8 years work experience in Technirel
(Techniques de la régulation)
is digital development with embedded microprocessors
and interface with PC.
- processor Intel 80C196KB
- language C, assembler
- process regulation by PID (Proportional, Integral, Derivative corrector)
- serial interface RS232C
I was making a great part of the development :
- hardware / software development
- synoptic figures
- electric figures
- choosing components
- implementation figures
- technical documentation
- commercial documentation
Some of my realizations :
UPN-T-R : regulator of alternator, 1 function voltage,
controlled by a power bridge of transistors.
Installed nearby a generator in Trans-Manche Link powersafe recovery center.
RG 730 : regulator of alternator 3 functions (rack 19'').
RG 730 MS : regulator of Synchronous Motor
The RG 730 MS in the middle :
Doors closed :
RG 730 PWM : regulator of alternator 3 functions,
controlling an IGBT power bridge by PWM.
RG 750 : regulator of alternator 3 functions, bi-processor (rack 19'').
From now on, CEE France and Technirel are a part of ICE group.
You'll get more informations from their website :
